-PLC control, servo motor controlled auger filling
-Full stainless steel machine construction,
-Full closure hopper design, ensure the safety dosing/packaging
-Oil pressure for up/ down, easy for position adjustment.
-No death angle, full polish surface treatment
-Easy augers-change for different filling range.
-*Option of dust collector
-*Option: S.S 316 contact parts
|
Model |
AF1000 |
AF5000 |
|
Products Filled: |
Powder, Small Granules |
|
Fill Speed: |
25-35 Fills/minute |
|
Containers Filled: |
Bags |
|
Fill Accuracy: |
±1% or better |
|
Fill Range: |
≤1000g |
≤5000g |
|
Operation: |
Automatic, with vffs packer |
|
Hopper Capacity: |
25L |
50L |
|
Construction: |
SS304, SS316 as option |
|
Cleaning/Changeover Time: |
20 minutes or less. |
|
Delivery Time |
Within 5 weeks. |
|
Special Features: |
Collector Funnel/Dust Collector/SS316 |
|
Voltage |
Single Phase, 220V,50/60HZ |
|
Power Consumption |
1.4KW
(Servo 750W, Agitator: 250W) |
2.2KW
(Servo 1000W, Agitator: 550W) |
|
Overall Dimension |
780×730×1690mm |
950×1000×2050mm |
|
Net Weight |
150Kg |
220Kg |
